PRODUCT HIGHLIGHTS
- RGBW Control of your existing LED strip or DC lighting straight from your Z-Wave hub
- Use with 12-24 V DC LED strips and fixtures
- Can be manually controlled from an on/off or momentary wall switch
-
800 series Z-Wave chip: delivers fast, secure, and highly reliable wireless performance
-
Z-Wave Long Range (ZWLR): when supported by your hub, it enables ultra-stable, long-distance direct communication to the device, reducing delays and dramatically expanding coverage
-
SmartStart and S2 authenticated security: ensure your smart home is set up securely from the start and stays fully protected
- Multicolor LED indicator for quick and effective troubleshooting
- Optional scene control* for multi-tap triggers from the connected wall switch
- Built-in signal repeater for your Z-Wave mesh
- 1-year warranty (extended 5-year warranty if registered within 30 days) & lifetime tech support
- Check out ZEN56 Frequently Asked Questions
NOTE: Z-Wave gateway controller (hub) required - sold separately. *You need a Z-Wave hub that supports these advanced features to take full advantage of the product.
WORKS WITH
- Z-Box Hub (recommended for Zooz products)
- Home Assistant (Z-Wave JS)
- HomeSeer
- Homey (Zooz App for Homey)
- Hubitat
- ISY (Universal Devices)
- SmartThings ((with custom driver, please note the current Android limitations in the linked article)
NOTE: If you don't see your Z-Wave controller on the list above, please contact us before you purchase this product.
TECHNICAL DETAILS
- Z-Wave Region: US / CA / MX
- Power: 12 / 24 V DC (Do NOT connect to 120 V AC)
- Maximum Load: 10 A TOTAL between all channels (6 A per channel max); 120 W total at 12 V DC / 240 W total at 24 V DC
- PWM Frequency: 244 Hz
-
Range: Up to 300 feet line of sight (or up to 1300 feet with ZWLR)
- Installation and Use: Indoor Only
- Operating Temperature: 32-104° F (0-40° C)
- Dimensions: 1.5" tall, 1.4" wide, 0.7" deep
RESOURCES
Zooz Z-Wave Plus S2 RGBW Dimmer ZEN56 Manual (PDF)
ZEN56 Frequently Asked Questions
